Warn Industries VR EVO 12 Electric WINCH – 103254

Warn Industries VR EVO 12 Electric winch – 103254. This electric winch is ideal for 3/4 and 1-ton pickups, as well as many sorts of heavy frame rigs requiring longer and heavier pulls. The VR EVO 12 is IP68-rated waterproof, has an ultra-reliable Albright® contactor within a relocatable control pack, and a cutting-edge, two-in-one remote for enhanced convenience and adaptability. The VR EVO winches, with their quick line-speed and decreased amp draw, are the hardest-working standard-duty winches we’ve ever manufactured, with tactical style that looks great up front and at a price that won’t break the bank.

Please keep in mind that this product cannot be installed on your vehicle without a matching bumper or mounting plate.

• A strong series-wound motor and planetary gear train provide quicker line speed under load while using less electricity.

• Waterproof winch construction certified IP68 keeps the elements out.

• The high-performance Albright contactor ensures utmost dependability.

• For low-profile installations, control packs can be moved.

Specifications

TYPE Electric
RECOMMENDED USE Vehicle Recovery
MOUNTING LOCATION Vehicle Mounted
VOLTAGE 12 Volt DC
ELECTRICAL CONTROL TYPE Albright Contactor
MOTOR TYPE Series Wound
DRIVE GEAR TYPE 3-Stage Planetary
GEAR REDUCTION RATIO 234:1
FREE SPOOLING Yes
BRAKE TYPE Spring
LINE DIAMETER (IN) 3/8 Inch
LINE LENGTH (FT) 85
LINE MATERIAL Steel
FAIRLEAD TYPE Roller
REMOTE TYPE 2 in 1 plug in remote with wireless capability
MOUNTING HOLE QUANTITY 4
MOUNTING PATTERN LENGTH (IN) 10 Inch
MOUNTING PATTERN WIDTH (IN) 4-1/2 Inch
INCLUDES MOUNTING HARDWARE Yes
COLOR Black
DRUM MATERIAL Steel
MAX LINE PULL/ LINE SPEED 12,000 pounds / 4.0 feet per minute
MAX AMP DRAW/ LINE PULL 396 Amps / 12,000 pounds



• One-piece cast-aluminum tie-plate for increased strength and durability

• Two-in-one remote with wired AND wireless capabilities for convenience and versatility

• Limited lifetime warranty on mechanical parts and 7 years on electrical components





SKU: 103254 Category:
